DAP AUDIO PALLADIUM 1600 VINTAGE

Output Power, 1000 Hz, THD+N at 1%,
Both Channels Driven:

Stereo mode: 8 Ohm: 2x 600 Watt RMS
4 Ohm: 2x 900 Watt RMS
2 Ohm: Not Allowed
Bridge mode: 8 Ohm: 1800 Watt RMS
4 Ohm: Not Allowed
Frequency Response: 20 - 45,000 Hz, -1 dB
THD+N: < 0.05%
Intermodulation Distortion: < 0.01%
Damping Factor at 8 Ohm: > 300
Slew Rate: > 40 V/µS
Input CMRR: > 60 dB
Crosstalk 20 - 20,000 Hz: > 60 dB
Signal to Noise Ratio: > 105 dB A-weighted
Input Sensitivity: 1 V~, +2.2 dBu
Max. Input Voltage: +22 dBu
Input Impedance: 20 kOhm Balanced
10 kOhm Unbalanced
